Standard configuration · platform with a gamma-ray spectrometer
AGF-1600 SPEKTR
AGF-1600 platform with an onboard scintillation detector.
The system comprises the AGF-1600 platform and an onboard scintillation detector. Flight range is 34 km, flight time 55 minutes, detector mass 4 kg.
UAS configuration
0.4 Lcrystal volume
7,2 %resolution (Cs-137)
take-off mass
1024number of channels
System
System for airborne gamma-ray spectrometry
System composition: carrier platform, geophysical instrument and software.
Onboard scintillation detectorThe onboard detector is installed on the standard mount with power and synchronisation connected.
System flight parametersFlight range of the system with the instrument installed is 34 km, flight time 55 minutes.
Spectrum positioningEach recorded spectrum is accompanied by position and time.
Spectrum processingThe system includes AGP-GAMMA-proc for channel-wise spectrum processing and conversion to concentrations.
Specifications
AGF-1600 SPEKTR system: carrier platform and onboard detector specifications.
| Parameter | Value |
|---|---|
| class | hexacopter, 6 arms |
| max. motor power | 1500 W |
| motor service life | up to 800 hours |
| take-off mass | 29 kg |
| range per flight | 34 km |
| flight time | 55 min |
| Parameter | Value |
|---|---|
No module selected — the configuration table appears once a module is chosen on the first screen. | |
Materials
Photos and documents
Views of the assembled system and the platform brochure.
